Introduction

welcome

Lovense offers several solutions for integrating with our products and services. Web camming and games are the most common integrations of our technology.

If you are in the camming industry, choose from our Cam Solutions. For other integrations, choose from our Standard Solutions. For a mobile integration, choose our Native SDK.

If you have any questions or additional requirements, please contact [email protected]

Cam Solutions (with Lovense Connect)

Whether you run a cam site or a service for the camming industry, our Cam Solutions will let you easily integrate our best-in-class technology into your platform. Add tip-activated vibrations to your platform and let your users join the 90,000+ models using Lovense on cam.

  • Cam Extension for Chrome

    Our Chrome extension - the most powerful camming tool for tip-activated toy control.

    Broadcast with any Lovense toy(s) and access a full range of custom features like tip vibrations, games, chatroom notifications, video overlays, and more.

    Cam sites we've integrated with this way:

    See the Documentation

  • Cam Kit for Web

    Integrate a JS file into your webpage to embed our core features and get basic functions like tip-activated vibrations.

    Offers you more control over the user's setup process, but fewer features for models.

    Cam sites we've integrated with this way:

    See the Documentation

  • Custom Cam Solution

    Our Basic APIs offer more customization.

    Cam sites we've integrated with this way:

Standard Solutions (with Lovense Remote)

Our Standard Solutions enable sending commands to Lovense toys by HTTP request. This is most commonly used by developers of games and other apps.

  • Standard API

    A simple method to send commands to Lovense toys.

    For integrating with
    PC Games
    PC Applications

    See the Documentation

  • Standard JS API

    A quick and convenient option for web-based games and apps.

    For integrating with
    Web Games
    Web Applications

    See the Documentation

Native SDK

Integrate Lovense features into your app using one of our SDKs.

For integrating with
iOS Apps
Android Apps
Windows Apps

See the Documentation

Cam Solutions

Cam Extension for Chrome

The Cam Extension for Chrome is the best solution for cam models to stream with Lovense toys, featuring:

  • Highly customizable vibration levels and patterns
  • Lovense widget for quick access to settings while streaming
  • Video overlay support for OBS, Streamster, SplitCam
  • Games and tools to increase interactivity and earn more tips
  • Frequent updates, improvements, and new features

Cam Extension Setting Page

Step 1: Configure the developer dashboard

FieldDescription
Website NameThe name that will be displayed in our cam site list (in the Cam Extension). Contact us if you want to change it.
Website URLYour home page URL.
Model Broadcasting Page PrefixThe URL prefix of your model broadcasting page.
StatusThe status of your website.

Go to the developer dashboardopen in new window and fill in your settings.

Status Meaning:

Pending - The website is being tested. Use test:{Website Name} name in order to add your website to the Cam Extension during the testing phase.

Active - The website is live and public. All models can see your cam site in the Cam Extension.

Step 2: Integration

Import the Javascript file

Import the Javascript file to your model’s broadcasting page. This Javascript will declare a global variable CamExtension on the page.

<script src="https://api.lovense.com/cam-extension/static/js-sdk/broadcast.js"></script>
1
Initialize the instance object

Initialize a CamExtension instance on the model’s live page.

/**
 * @param {string} websiteName this is the Website Name shown in the developer dashboard
 * @param {string} modelName this is the model's name
 * @returns {object} CamExtension instance object
 */
const camExtension = new CamExtension(websiteName, modelName)
1
2
3
4
5
6
Listen for ready event

Listen for the ready event, which will be called after successful initialization. You can communicate with the Cam Extension after this event is triggered.

/**
 * readyCallback
 * @param {object} ce CamExtension instance object
 */
const readyCallback = function (ce) {
  // Handle the CamExtension instance object
  // e.g. await ce.getCamVersion()
}

camExtension.on("ready", readyCallback)
1
2
3
4
5
6
7
8
9
10

Step 3: Methods & events

Methods
  • receiveTip

    Call this method when the model receives a tip. The Cam Extension will trigger a response in the toy according to these parameters:

    /**
     * receiveTip
     * @param {number} amount  tip amount that the model receives
     * @param {string} tipperName this is the tipper’s Screen Name
     */
    camExtension.receiveTip(amount, tipperName)

    1
    2
    3
    4
    5
    6
  • receiveMessage

    Call this method when the model receives a message in the chat room.

    /**
     * receiveMessage
     * @param {string} userName  the sender’s Screen Name
     * @param {string} content the message just sent by the sender
     */
    camExtension.receiveMessage(userName, content)

    1
    2
    3
    4
    5
    6
  • getSettings

    Get the model's Lovense Settings.

    /**
     * getSettings
     * @returns {object} model's Lovense Settings
     */
    const data = await camExtension.getSettings()
    // data = {
    //  levels: {
    //    level1: {
    //     min: 1,
    //     max: 9,
    //     time: 2,
    //     rLevel: 0,
    //     vLevel: 0,
    //    },
    //    level2: {...}
    //    level3: {...}
    //  },
    //  special: {
    //    earthquake: {
    //      time: "22",
    //      token: "120",
    //    },
    //    fireworks: (...),
    //    giveControl: (...),
    //    pause: (...),
    //    pulse: (...),
    //    random: (...),
    //    twowaves: (...),
    //    wave: (...),
    //  }
    // }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
  • getToyStatus

    Get the model's Lovense Toys status.

    /**
     * getToyStatus
     * @returns {array} model's Lovense Toys status.
     */
    const data = await camExtension.getToyStatus()
    // data = [
    //  {
    //    id: "l58f167da065",
    //    name: "",
    //    type: "lush",
    //    status: "on"
    //  },
    //  {...}
    // ]

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
  • getCamVersion

    Get the Cam Extension version.

    /**
     * getCamVersion
     * @returns {string} Cam Extension version
     */
    const data = await camExtension.getCamVersion()
    // data = "30.4.4"

    1
    2
    3
    4
    5
    6
Events

You can listen for certain events to get the latest real-time data

  • postMessage

    We will trigger this event when we need to send a message to you or the chat room, and you will need to help us handle it accordingly.

    camExtension.on("postMessage", (message) => {
      // Process the message to be sent
      // Send the message to chat room
      // e.g. message = "My LOVENSE Lush is now reacting to john's tip. It will stop after 5 sec!"
    })

    1
    2
    3
    4
    5
  • toyStatusChange

    We will trigger this event when the toy status changes.

    camExtension.on("toyStatusChange", (data) => {
      // Handle toy information data
      // data = [{
      //  id: "d6c35fe83348",
      //  name: "toy's name",
      //  type: "lush",
      //  status: "on",
      //  version: "",
      //  battery: "80"
      // }]
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
  • tipQueueChange

    We will trigger this event when the tip queue updates.

    camExtension.on("tipQueueChange", (data) => {
      //  handle queue information data
      //  data = {
      //   running: [
      //    {
      //      amount: 100,
      //      tipperName: "john",
      //      time: 20,
      //      module: "Special Command",
      //      cParameter: {},
      //      level: "",
      //      specialType: "earthquake",
      //      modelName: "coco",
      //      reactToys: [,
      //        toyId: "d6c35fe83348",
      //        specialType: "earthquake",
      //        status: 1,
      //        toyType: "lush",
      //      ]
      //    }
      //   ],
      //   queue: [...],
      //   waiting: [...]
      //  }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
  • settingsChange

    We will trigger this event when the model’s Lovense Settings are updated.

    camExtension.on("settingsChange", (data) => {
      //  handle configuration information data
      // data = {
      //  levels: {
      //    level1: {
      //     min: 1,
      //     max: 9,
      //     time: 2,
      //     rLevel: 0,
      //     vLevel: 0,
      //    },
      //    level2: {...}
      //    level3: {...}
      //  },
      //  special: {
      //    earthquake: {
      //      enable: true,
      //      time: "20",
      //      token: "100",
      //    },
      //    fireworks: (
      //      enable: true,
      //      time: "22",
      //      token: "120",
      //    ),
      //    giveControl: (
      //      enable: false,
      //      time: "",
      //      tokensBegin: "",
      //      tokensEnd: "",
      //    ),
      //    randomTime: (
      //      enable: true,
      //      tokens: "38",
      //      minTime: 10,
      //      maxTime: 50,
      //      level: 5,
      //    ),
      //    pause: (...),
      //    pulse: (...),
      //    random: (...),
      //    wave: (...),
      //  }
      // }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45

Cam Kit for Web

Work Flow

Step 1: Configure the developer dashboard

Go to the developer dashboardopen in new window

  1. Get your dToken (Developer Token).
  2. Click "Cam Kit Developer settings (v2.0)", configure your settings.

Step 2: Generate an mToken for your model

Get a unique token for your model. You only need to do this once for each model.

API URL: https://api.lovense.com/api/cam/model/getToken

Notice: For security reasons, the developer token should be always used on the server side. You should never use it in your JS code from the client side.

HTTP Request: POST

Content Type: application/x-www-form-urlencoded; charset=UTF-8

Parameters:

NameDescription
dTokenDeveloper Token
mInfoModel's Information (UTF-8 encoded JSON)

Sample request:

// content-type: application/x-www-form-urlencoded; charset=UTF-8
{
  "dToken": "xxxx", // developer token
  "mInfo": "{'mId':'b799e042b','mName':'test123'}" //
}
1
2
3
4
5

Return:

{
  "result": true, // true or false
  "message": "SuccessFully",
  "code": 200, // 200: OK 401: Invalid token 402: Invalid user information 505: Other Errors
  "data": {
    "mId": "b799e042b",
    "mToken": "95116bd2af44b753da2a1e4cd55cf965" // got mToken
  }
}
1
2
3
4
5
6
7
8
9
NameDescription
resulttrue if successful, false if failed
messageRequest result
dataDetailed description
code200: OK, 401: Invalid token, 402: Invalid user information, 505: Other Errors

Step 3: Model configures their Lovense settings

Display the Lovense settings page on the model's side. You can put this page in a new window or an iframe.

After you modify your settings, the new settings will take around 10 seconds to take effect.

Settings page: https://api.lovense.com/api/cam/model/v2/setting?mToken={mToken}

Sample code:

lovense.settingPage = window.open(
  "https://api.lovense.com/api/cam/model/v2/setting?mToken={mToken}"
)
1
2
3

or

<iframe
  id="lovense-setting"
  width="100%"
  height="1500px"
  scrolling="no"
  src="https://api.lovense.com/api/cam/model/v2/setting?mToken={mToken}"
></iframe>
1
2
3
4
5
6
7

Step 4: Broadcasting process & methods

Include the model.js on your broadcasting page.

<script src="https://api.lovense.com/api/cam/model/v2/model.js?mToken={mToken}"></script>
1

Call lovense.addMessageListener(callback) after the live page is loaded, and handle these types of messages in the callback function:

Events
  • message

    lovense.addMessageListener(function (data) {
      // data = {
      //  type: "message",
      //  detail: "some customized messages to be sent to the public chat room."
      //  e.g. detail = "My LOVENSE Lush is now reacting to john's tip. It will stop after 5 sec!"
      //}
    })

    1
    2
    3
    4
    5
    6
    7
  • settings

    lovense.addMessageListener(function (data) {
      // Handle settings information
      // data = {
      //  type: "settings",
      //  detail: {
      //   levels: {
      //     level1: {
      //      min: "1",
      //      max: "9",
      //      time: "2",
      //      rLevel: 0,
      //      vLevel: 0,
      //     },
      //     level2: {...}
      //     level3: {...}
      //   },
      //   special: {
      //     earthquake: {
      //       time: "22",
      //       token: "120",
      //     },
      //     fireworks: (...),
      //     giveControl: (...),
      //     pause: (...),
      //     pulse: (...),
      //     random: (...),
      //     twowaves: (...),
      //     wave: (...),
      //   }
      //  }
      // }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
  • toy

    lovense.addMessageListener(function (data) {
      // Handle toy information data
      // data = {
      //  type: "toy",
      //  status: "on"
      //  detail: [
      //   {
      //     id: "l58f167da065",
      //     name: "",
      //     type: "lush",
      //     status: "on"
      //   }
      //  ]
      // }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
  • tipQueueStatus

    lovense.addMessageListener(function (data) {
      // handle queue information data
      // data = {
      //  type: "tipQueueStatus",
      //  detail: {
      //   running: [
      //    {
      //      amount: 20,
      //      tipperName: "john",
      //      time: 30,
      //      cParameter: {},
      //      level: 5,
      //      module: "Basic Level"
      //      specialType: undefined,
      //      name: "coco",
      //      reactToys: [,
      //        toyId: "d6c35fe83348",
      //        specialType: "earthquake",
      //        status: 1,
      //        toyType: "lush",
      //        vibrate: 20,
      //        rotate: 0,
      //        airpump: 0,
      //      ]
      //    }
      //   ],
      //   queue: [
      //    {
      //      amount: 20,
      //      tipperName: "john",
      //    }
      //   ],
      //   waiting: [...]
      //  }
      // }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
  • tipRunning

    lovense.addMessageListener(function (data) {
      // handle running tip information
      // data = {
      //  type: "tipRunning",
      //  detail: {
      //   running: [
      //    {
      //      amount: 20,
      //      tipperName: "john",
      //      time: 30,
      //      cParameter: {},
      //      level: 5,
      //      module: "Basic Level"
      //      specialType: undefined,
      //      name: "coco",
      //      reactToys: [,
      //        toyId: "d6c35fe83348",
      //        specialType: "earthquake",
      //        status: 1,
      //        toyType: "lush",
      //        vibrate: 20,
      //        rotate: 0,
      //        airpump: 0,
      //      ]
      //    }
      //   ]
      //  }
      // }
    })

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
Methods
  • initCamApi

    If your website is a single page application, when the model enters the broadcasting page call initCamApi.

    /**
     * initCamApi
     * @param {string} mToken  model token
     */
    lovense.initCamApi(mToken)

    1
    2
    3
    4
    5
  • destroyCamApi

    When the model ends the live broadcast or signs out, call destroyCamApi.

    lovense.destroyCamApi()

    1
  • receiveTip

    Once a tip is received, call Lovense.receiveTip(cname,amount). Toys will respond according to the settings.

    /**
     * receiveTip
     * @param {string} cname  this is the tipper’s Screen Name
     * @param {number} amount  token amount
     */
    lovense.receiveTip(cname, amount)
    // e.g. lovense.receiveTip('cname', 1)

    1
    2
    3
    4
    5
    6
    7
  • getToys

    Use getToys() to get the toy info of models

    /**
     * getToys
     * @returns {array} toy information
     */
    lovense.getToys()

    1
    2
    3
    4
    5

    Return:

    [
      {
        "id": "XXXXXXXXXXXX",
        "name": "",
        "status": "on",
        "type": "lush"
      }
    ]

    1
    2
    3
    4
    5
    6
    7
    8
  • getSettings

    Use getSettings to get the settings info of models

    /**
     * getSettings
     * @returns {object} settings information
     */
    lovense.getSettings()

    1
    2
    3
    4
    5

    Return:

    {
        levels: {
          level1: {
            max: 10, // tip level range maximum
            min: 3,  // tip level range minimum
            rLevel: 0, // rotation level
            time: 3, // duration (seconds)
            vLevel: 5  // vibration level
          },
          ...
        },
        special: {
          clear: {
            token: 20 // number of tokens
          },
          earthquake: (...),
          fireworks: (...),
          giveControl: (...),
          pause: (...),
          pulse: (...),
          random: (...),
          twowaves: (...),
          wave: (...)
        }
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25

Display Panel (optional)

The Lovense Display Panel makes the show much more interactive compared to simple text based tip activation. We currently provide 2 panels for your tippers/viewers.

  • Control Panel - This enables a new tip menu item called Give Control. It automatically generates a control link for the tipper when they tip for this item, allowing models to give direct control of their toys to tippers much more easily.

Control Panel

  • Tip Panel - Show the model's tip menu directly on the viewer's page.

Control Panel

Step 1: Turn on the Display Panel on your Lovense Developer Dashboard

Control Panel

You will get a default AES KEY and AES IV that are used for encryption. Use them to encrypt the model name and the tipper name.

Step 2: Import the tipper.js to your tipper's page

<script src="https://api.lovense.com/api/cam/tipper/v2/tipper.js"></script>
1

Step 3: Initialize

Lovense.init(platform, modelKey, tipperKey)
1

Parameters

NameDescriptionRequired
platformYour Website Name (shown in the Developer Dashboard)yes
modelKeyThe model name encrypted on your server side using the AES KEY and AES IV. Do not expose your Key/IV in your JS code. (There is a demo on how to encrypt text using AES in JAVA below)yes
tipperKeyThe tipper name encrypted using the AES KEY and AES IV (The tipper name should be the Display Name showing in the public broadcasting room)yes

⚠️ Display Panels are only available when the model is using Cam Extension version 30.0.8+

If your website is a single page application, when the tipper leaves the model's room, call:

Lovense.destroy()
1

Here is the demo on how to encrypt text using AES in JAVA:

import org.apache.commons.codec.binary.Base64;

import javax.crypto.Cipher;
import javax.crypto.spec.IvParameterSpec;
import javax.crypto.spec.SecretKeySpec;
import java.security.AlgorithmParameters;
import java.security.Key;

public class AESDemo {

    private static Key getKey(String key)  throws Exception{
        byte[] keyBytes = key.getBytes("UTF-8");
        SecretKeySpec newKey = new SecretKeySpec(keyBytes, "AES");
        return newKey;
    }
    private static AlgorithmParameters getIV(String iv) throws Exception {
        byte[] ivs = iv.getBytes("UTF-8");
        AlgorithmParameters params = AlgorithmParameters.getInstance("AES");
        params.init(new IvParameterSpec(ivs));
        return params;
    }

    public static String encrypt(String key,String iv,String text) throws Exception {

        Cipher cipher = Cipher.getInstance("AES/CBC/PKCS5Padding");
        cipher.init(Cipher.ENCRYPT_MODE, getKey(key), getIV(iv));
        byte[] encryptedBytes = cipher.doFinal(text.getBytes());
        return new String(Base64.encodeBase64(encryptedBytes, false,true),"UTF-8");
    }

    public static String decrypt(String key,String iv,String text) throws Exception {
        byte[] textBytes = Base64.decodeBase64(text);
        Cipher cipher = Cipher.getInstance("AES/CBC/PKCS5Padding");
        cipher.init(Cipher.DECRYPT_MODE, getKey(key), getIV(iv));
        byte[] decodedBytes = cipher.doFinal(textBytes);
        return new String(decodedBytes, "UTF-8");
    }

    public static void main(String[] args) throws Exception{
        String key="jHZZwiizsAF2qTAY";  //use your own Key here
        String iv="zijknVpNWeeTYGPV";  //use your own IV here
        String test="Hello World!";
        System.out.println(encrypt(key,iv,test));;
        System.out.println(decrypt(key,iv,encrypt(key,iv,test)));;
    }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46

Step 4: Data Forwarding

Lovense will notify you when the Model Status has changed, and you should send the Model Status back to the tipper.js. Here is the Flow Chart:

Display Panel

How does it work?

Contact us to provide your callback URL. Lovense will post ModelStatus to your callback URL when necessary (for example, when the model enables/disables features during their broadcast). You forward the ModelStatus to the tipper/viewer's page and reply to the callback request with "OK". Then call Lovense.recieveData(data) on the tipper/viewer's page.

Description of the Callback Request

URL: your callback url

Request Protocol: HTTPS Request

Method: POST

Content Type: application/json

the ModelStatus Object::

{
  "from":"ABCDxxxxxxxxxxxx", //Encrypted String using your AES KEY and IV
  "to": {
    "type":"customersOfModel", //which group of people you should forward to
    "target":"Lucy,Tony" // users you should forward the data to
  },
  "data": data // the data you should forward
}
1
2
3
4
5
6
7
8

Attributes in ModelStatus

  • from [String]: Encrypted string of "Lovense" using your AES KEY. If you can decrypt it with your AES KEY, you can confirm that the data is from Lovense. It is a static string until you changed your AES KEY in Lovense Dashboard.
  • to [Object]: Whom you should forward the data to
  • to.type [String]: Which group of people you should forward the data to. Possible values: customersOfModel, customers
  • to.target [String]: Users you should forward to
    • If the to.type is customersOfModel, the to.target is the model's name (separated with commas if there are multiple values), and you should forward the data to all the customers in the specified model's broadcasting room.
    • If the to.type is customer, the to.target is the tipper/viewer's screen name (separated with commas if there are multiple values), and you should forward the data to the specified tipper/viewer
  • data [String]: the data that you should forward

Here is a sample written in JAVA for handling the callback from Lovense:

private final String KEY = "Your KEY";
private final String IV = "Your IV";
private final String AESFrom = AESUtil.encrypt("Lovense",KEY,IV);

@RequestMapping(value = "/lovense/callback")
public @ResponseBody String callback(@RequestBody Map<String,Object> modelStatus) {

  //1. If from is same as AESFrom
  if(AESFrom.equals(modelStatus.get("from"))){
    Map<String,String> to = (Map<String, String>) modelStatus.get("to");
    String data = (String) modelStatus.get("data");

    //2. Handle different target groups
    switch (to.get("type")){
      case "customersOfModel":
      String modelName = to.get("target");
      //3.1 TODO forward `data` to the tippers/viewers in the model's room
      break;
    case "customer":
      String customerScreenName = to.get("target");
      //TODO forward `data` to the tippers/viewers
      break;
    default:
      break;
    }
  }
  //4. Reply "OK"
  return "OK";
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

Custom Cam Solution

Basic API

This API allows developers to access Lovense toys through simple HTTPS request. Configure your settings on our developer dashboard before getting started.

Step 1: Configure the developer dashboard

Go to the developer dashboardopen in new window, select "Standard API" tab, enter your application info.

  • Website Name: The name that will be displayed in Lovense Connect. Contact us if you want to change it.

  • Callback URL: This is the URL from your server where our app sends callback information.

  • Heartbeat: The callback interval for our app to update your server with the latest status.

Step 2: Connect to Lovense toy(s)

We offer 2 ways to connect to our toys.

  • Connect by Lovense Connect (iOS & Android version)

    Users need to install Lovense Connect mobile app on their iOS/Android devices.

    1. The user pairs their Lovense toy to the Lovense Connect app.

    2. Get the QR code to connect to Lovense Connect.

      Call Lovense Server API from your server

      API URL: https://api.lovense.com/api/lan/getQrCode

      Notice: For security reasons, the developer token should be always used on the server side. You should never use it in your JS code from the client side.

      Request Protocol: HTTPS Request

      Method: POST

      Content Type: application/json

      Parameters:

      NameDescriptionRequired
      tokenDeveloper Tokenyes
      uidUser ID on your applicationyes
      unameUser ID on your applicationno
      utokenUser token from your website. This is for your own verification purposes. We suggest you generate a unique token for each user. This allows you to verify the user and avoid others faking the calls.no
      vversionyes

      Request Example:

      {
        "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
        "uid": "42425232242",
        "v": 2
      }

      1
      2
      3
      4
      5

      Return:

      {
        code: 0
        result: true
        message: "Success"
        data: {
            "qr": "https://test2.lovense.com/UploadFiles/qr/20220106/xxxx.jpg", // qrcode picture
            "code": "xxxx"
        }
      }

      1
      2
      3
      4
      5
      6
      7
      8
      9

      API will return a JSON object that contains the QR code image URL. You will get:

      NameDescription
      codeError code
      messageresult
      resulttrue if successful, false if failed
      dataqrcode picture, code

      Display the QR code image to the user

    3. Users scan the QR code using Lovense Connect.

    Once the user scans the QR code with the Lovense Connect app, the app will invoke the callback URL you provided on the developer dashboard.

    Here's the JSON data Lovense Connect app will post to your server:

    {
      uid: User ID
      utoken: xxx, // User token on your application
      domain: 192-168-0-11.lovense.club, // the domain name of the Lovense Connect app
      httpPort: 34567, // HTTP server port
      wsPort: 34567, // HTTP server port
      httpsPort: 34568, //HTTPS server port
      wssPort: 34568, // HTTPS server port
      platform: 'ios', // the Lovense Connect platform e.g. Android/iOS
      appVersion: '2.3.6', //the Lovense Connect version
      version: 101, // the protocol version e.g. 101
      toys:{
          toyId:{
            id: xxxxxx, // Toy's ID
            name:"lush", // toy's name
            nickName: "nickName"
            status: 1 // e.g. 1/0
          }
        }
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20

    The domain and httpPort used to connect to Lovense Connect (iOS & Android) are returned.

  • Connect by Lovense Connect (PC & Mac version) on the same computer

    Windows computers - Users need the Lovense USB Bluetooth Adapter.

    Mac - Users can connect our toys directly to their Mac via Bluetooth.

    1. The user pairs their Lovense toy to Lovense Connect for PC/Mac.
Step 3: Command the toy(s)

Once everything is set up, you can command our toys:

  • Local APIs: These APIs are exposed by Lovense Connect app through HTTPS. The connections are in the same LAN or the same computer.
  • Server APIs: If your application can’t establish a LAN connection to the user’s Lovense Connect, you can use the Server API to connect the user’s toy.
By local application

⚠️ iOS Connect v2.6.4, Android Connect v2.7.7, PC Connect 1.5.4 are required.

If the user's device is in the same LAN environment, a POST request to Lovense Connect can be used to trigger a toy response. In this case, both your server and Lovense's server are not required.

If the user has Lovense Connect mobile, the domain and httpsPort are accessed from the callback information. If the user has Lovense Connect for PC/Mac, the domain is 127-0-0-1.lovense.club, and the httpsPort is 30010.

With the same command line, different parameters will lead to different results as below.

  • GetToys Request

    Get the user's toy(s) information.

    API URL: https://{domain}:{httpsPort}/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes

    Request Example:

    {
      "command": "GetToys"
    }

    1
    2
    3

    Response Example:

    {
      "code": 200,
      "data": {
        "toys": "{  \"fc9f37e96593\" : {    \"id\" : \"fc9f37e96593\",    \"status\" : \"1\",    \"version\" : \"\",    \"name\" : \"nora\",    \"battery\" : 100,    \"nickName\" : \"\"  }}",
        "platform": "ios",
        "appType": "connect"
      },
      "type": "OK"
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
  • Function Request

    API URL: https://{domain}:{httpsPort}/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    actionControl the function and strength of the toystringActions can be Vibrate, Rotate, Pump or Stop. Use Stop to stop the toy’s response.
    Range:
    Vibrate:0 ~ 20
    Rotate: 0~20
    Pump:0~3
    yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    loopRunningSecRunning timedoubleShould be greater than 1.no
    loopPauseSecSuspend timedoubleShould be greater than 1.no
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    stopPreviousStop all previous commands and execute current commandsintDefault: 1, If set to 0 , it will not stop the previous command.no
    apiVerThe version of the requestintAlways use 1yes

    Parameter stopPrevious are available in the following versions: Android Connect 2.7.6, iOS Connect 2.7.2, PC Connect 1.5.9 .

    Request Example:

    // Vibrate toy ff922f7fd345 at 16th strength, run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "command": "Function",
      "action": "Vibrate:16",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    // Vibrate 9 seconds at 2nd strength
    // Rotate toys 9 seconds at 3rd strength
    // Pump all toys 9 seconds at 4th strength
    // For all toys, it will run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "command": "Function",
      "action": "Vibrate:2,Rotate:3,Pump:4",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
  • Pattern Request

    If you want to change the way the toy responds very frequently you can use a pattern request. To avoid network pressure and obtain a stable response, use the commands below to send your predefined patterns at once.

    API URL: https://{domain}:{httpsPort}/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    rule"V:1;F:vrp;S:1000#"
    V:1; Protocol version, this is static;
    F:vrp; Features: v is vibrate, r is rotate, p is pump, this should match the strength below;
    S:1000; Intervals in Milliseconds, should be greater than 100.
    stringThe strength of r and p will automatically correspond to v.yes
    strengthThe pattern
    For example: 20;20;5;20;10
    stringNo more than 50 parameters. Use semicolon ; to separate each strength.yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will apply to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy as defined. The interval between changes is 1 second. Total running time is 9 seconds.
    {
      "command": "Pattern",
      "rule": "V:1;F:v;S:1000#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    // Vibrate the toys as defined. The interval between changes is 0.1 second. Total running time is 9 seconds.
    // If the toys include Nora or Max, they will automatically rotate or pump, you don't need to define it.
    {
      "command": "Pattern",
      "rule": "V:1;F:vrp;S:100#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
  • Preset Request

    API URL: https://{domain}:{httpsPort}/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    namePreset pattern namestringWe provide four preset patterns in the Lovense Connect app: pulse, wave, fireworks, earthquakeyes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy with pulse pattern, the running time is 9 seconds.
    {
      "command": "Preset",
      "name": "pulse",
      "timeSec": 9,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8

Response Example:

{
  "code": 200,
  "type": "ok"
}
1
2
3
4

Error Codes:

CodeMessage
500HTTP server not started or disabled
400Invalid Command
401Toy Not Found
402Toy Not Connected
403Toy Doesn't Support This Command
404Invalid Parameter
506Server Error. Restart Lovense Connect.
By server

If your application can’t establish a LAN connection to the user’s Lovense Connect, you can use the Server API to connect the user’s toy.

⚠️ Coming soon to PC Connect.

  • Function Request

    API URL: https://api.lovense.com/api/lan/v2/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Request Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringTo send commands to multiple users at the same time, add all the user IDs separated by commas. The toy parameter below will be ignored and the commands will go to all user toys by default.yes
    commandType of requestString/yes
    actionControl the function and strength of the toystringActions can be Vibrate, Rotate, Pump or Stop. Use Stop to stop the toy’s response.
    Range:
    Vibrate:0 ~ 20
    Rotate: 0~20
    Pump:0~3
    yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    loopRunningSecRunning timedoubleShould be greater than 1no
    loopPauseSecSuspend timedoubleShould be greater than 1no
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    stopPreviousStop all previous commands and execute current commandsintDefault: 1, If set to 0 , it will not stop the previous command.no
    apiVerThe version of the requestintAlways use 1yes

    Parameter stopPrevious are available in the following versions: Android Connect 2.7.6, iOS Connect 2.7.2 PC Connect 1.5.9 .

    Request Example:

    // Vibrate toy ff922f7fd345 at 16th strength, run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1132fsdfsd",
      "command": "Function",
      "action": "Vibrate:16",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    // Vibrate 9 seconds at 2nd strength
    // Rotate toys 9 seconds at 3rd strength
    // Pump all toys 9 seconds at 4th strength
    // For all toys, it will run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1132fsdfsd",
      "command": "Function",
      "action": "Vibrate:2,Rotate:3,Pump:4",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    // Stop all toys
    {
      "command": "Function",
      "action": "Stop",
      "timeSec": 0,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
  • Pattern Request

    If you want to change the way the toy responds very frequently you can use a pattern request. To avoid network pressure and obtain a stable response, use the commands below to send your predefined patterns at once.

    API URL: https://api.lovense.com/api/lan/v2/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringTo send commands to multiple users at the same time, add all the user IDs separated by commas. The toy parameter below will be ignored and the commands will go to all user toys by default.yes
    commandType of requestString/yes
    rule"V:1;F:vrp;S:1000#"
    V:1; Protocol version, this is static;
    F:vrp; Features: v is vibrate, r is rotate, p is pump,this should match the strength below;
    S:1000; Intervals in Milliseconds, should be greater than 100.
    stringThe strength of r and p will automatically correspond to v.yes
    strengthThe pattern
    For example: 20;20;5;20;10
    stringNo more than 50 parameters. Use semicolon ; to separate every strength.yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will apply to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy as defined. The interval between changes is 1 second. Total running time is 9 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1ads22adsf",
      "command": "Pattern",
      "rule": "V:1;F:v;S:1000#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    // Vibrate the toys as defined. The interval between changes is 0.1 second. Total running time is 9 seconds.
    // If the toys include Nora or Max, they will automatically rotate or pump, you don't need to define it.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1ads22adsf",
      "command": "Pattern",
      "rule": "V:1;F:vrp;S:100#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
  • Preset Request

    API URL: https://api.lovense.com/api/lan/v2/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Request Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringTo send commands to multiple users at the same time, add all the user IDs separated by commas. The toy parameter below will be ignored and the commands will go to all user toys by default.yes
    commandType of requestString/yes
    namePreset pattern namestringWe provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquakeyes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy with pulse pattern, the running time is 9 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1adsf2323",
      "command": "Preset",
      "name": "pulse",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9

Response Example:

{
  "result": true,
  "code": 200,
  "message": "Success"
}
1
2
3
4
5

Server Error Codes:

CodeMessage
200Success
400Invalid command
404Invalid Parameter
501Invalid token
502You do not have permission to use this API
503Invalid User ID
507Lovense APP is offline

Basic JS API

This solution allows you to control Lovense toys through your webpage.

Your users must pair their toy(s) to the Lovense Connect app for mobile or PC.

⚠️ iOS Connect v2.6.4+, Android Connect v2.7.7+, or PC Connect 1.5.4+ is required.

⚠️ User's devices must be in the same LAN.

Step 1: Set your callback URL

Go to the developer dashboardopen in new window and set your Callback URL.

Set your Callback URL

Step 2: Import the LAN.JS to your user's page

Add our LAN.JS to your user's page.

<script src="https://api.lovense.com/api/lan/v2/lan.js"></script>
1
Step 3: Handle the callback data from Lovense Connect

You can listen to the callback from Lovense Connect as below:

// the path should be the same as you set in the Lovense developer dashboard
@RequestMapping(value = "/api/lovense/callback")
public @ResponseBody
MessageResponse callback(@RequestBody Map body) {
  //TODO
  //send the callback data to the user's page and call `lovense.setConnectCallbackData` there
  return new MessageResponse(true, "success");
}
1
2
3
4
5
6
7
8

Call lovense.setConnectCallbackData with the callback data you received from Lovense Connect in the user's page to initialize the LAN.JS.

lovense.setConnectCallbackData(callbackData)
1

⚠️ If the user uses Lovense Connect for PC, this step can be skipped because a QR code is not required.

Step 4: Command the toy(s)

Send commands to Lovense toy(s) by calling lovense.sendCommand(parameters).

For the parameters list, see Command the toy(s).

Example:

lovense.sendCommand({
  command: "Function",
  action: "Vibrate:16",
  timeSec: 20,
  loopRunningSec: 9,
  loopPauseSec: 4,
  toy: "ff922f7fd345",
  apiVer: 1,
})
1
2
3
4
5
6
7
8
9
Other methods
  • getToys

    Get all toys, it will return all toys as an array

    lovense.getToys()

    1
  • getOnlineToys

    Get all online toys, it will only return the connected toys as an array

    lovense.getOnlineToys()

    1
  • isToyOnline

    Determine whether the toy is connected, it will return true as long as there is a toy connected.

    lovense.isToyOnline()

    1
  • openMobileConnect

    Open Lovense Mobile Connect.

    lovense.openMobileConnect()

    1

Standard Solutions

These solutions allow you to control users' Lovense toys by simple HTTPS request.

If you want to integrate with your website or web app, we suggest you use our Standard JS API.

If you integrate a Standard Solution, your users must use Lovense Remote to pair their toys. Lovense Remote is available on Google Play and the App Store.

Lovense Remote App

Standard API

This API allows any application to access its users Lovense toys from the developer side.

Step 1: Configure the developer dashboard

Go to the developer dashboardopen in new window and set your Callback URL.

Set your Callback URL

Step 2: Find your user's toy(s)

  1. Get your developer token from the Lovense developer dashboard.

  2. Your server calls Lovense server's API (use POST request)

    For example:

    String url= "https://api.lovense.com/api/lan/getQrCode";
    Map<String, String> requestParameter = new HashMap<String, String>();
    //TODO initialize your parameters:
    requestParameter.put("token", "{Lovense developer token}");
    requestParameter.put("uid", "{user ID on your website}");
    requestParameter.put("uname", "{user nickname on your website}");
    requestParameter.put("utoken", "{Encrypted user token on your application. This is a security consideration, to avoid others stealing control of the toy.}");
    requestParameter.put("v", 2);
    HttpPost httpPost = new HttpPost(url);
    List<NameValuePair> nameValuePairs = new ArrayList<NameValuePair>();
    if (requestParameter != null && !requestParameter.isEmpty()) {
      Set<String> keys = requestParameter.keySet();
      for (String key : keys) {
        nameValuePairs.add(new BasicNameValuePair(key, requestParameter.get(key)));
      }
    }
    httpPost.setEntity(new UrlEncodedFormEntity(nameValuePairs, "utf-8"));

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    const result = await axios.post(
      "https://api.lovense.com/api/lan/getQrCode",
      {
        token: "your developer token", // Lovense developer token
        uid: "11111", // user ID on your website
        uname: "user name", // user nickname on your website
        utoken: md5(uid + "salt"), // This is for your own verification purposes. We suggest you to generate a unique token/secret for each user. This allows you to verify the user and avoid others faking the calls.
        v: 2,
      }
    )

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10

    You will get:

    {
       code: 0
       message: "Success"
       result: true
       data: {
         "qr": "https://test2.lovense.com/UploadFiles/qr/20220106/xxx.jpg", // QR code picture
         "code": "xxxxxx"
       }
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
  3. Once the user scans the QR code with the Lovense Remote app, the app will invoke the Callback URL you've provided in the developer dashboard. The Lovense server is no longer required. All communications will go from the app to your server directly.

    Here's the JSON data Lovense Remote app will post to your server:

    {
      "uid": "xxx",
      "appVersion": "4.0.3",
      "toys": {
        "xxxx": {
          "nickName": "",
          "name": "max",
          "id": "xxxx",
          "status": 1
        }
      },
      "wssPort": "34568",
      "httpPort": "34567",
      "wsPort": "34567",
      "appType": "remote",
      "domain": "192-168-1-44.lovense.club",
      "utoken": "xxxxxx",
      "httpsPort": "34568",
      "version": "101",
      "platform": "android"
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21

Step 3: Command the toy(s)

Note: iOS Remote 5.1.4+, Android Remote 5.1.1+, or PC Remote 1.5.8+ is required.

By local application

If the user's device is in the same LAN environment, a POST request to Lovense Remote can trigger a toy response. In this case, your server and Lovense's server are not required.

If the user uses the mobile version of Lovense Remote app, the domain and httpsPort are accessed from the callback information. If the user uses Lovense Remote for PC, the domain is 127-0-0-1.lovense.club, and the httpsPort is 30010

With the same command line, different parameters will lead to different results as below.

  • GetToys Request

    Get the user's toy(s) information.

    API URL: https://{domain}:{httpsPort}/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes

    Request Example:

    {
      "command": "GetToys"
    }

    1
    2
    3

    Response Example:

    {
      "code": 200,
      "data": {
        "toys": "{  \"fc9f37e96593\" : {    \"id\" : \"fc9f37e96593\",    \"status\" : \"1\",    \"version\" : \"\",    \"name\" : \"nora\",    \"battery\" : 100,    \"nickName\" : \"\"  }}",
        "platform": "ios",
        "appType": "remote"
      },
      "type": "OK"
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
  • Function Request

    API URL: https://{domain}:{httpsPort}/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    actionControl the function and strength of the toystringActions can be Vibrate, Rotate, Pump or Stop. Use Stop to stop the toy’s response.
    Range:
    Vibrate:0 ~ 20
    Rotate: 0~20
    Pump:0~3
    yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    loopRunningSecRunning timedoubleShould be greater than 1no
    loopPauseSecSuspend timedoubleShould be greater than 1no
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    stopPreviousStop all previous commands and execute current commandsintDefault: 1, If set to 0 , it will not stop the previous command.no
    apiVerThe version of the requestintAlways use 1yes

    Parameter stopPrevious are available in the following versions: Android Remote 5.2.2, iOS Remote 5.4.4, PC Remote 1.6.3 .

    Request Example:

    // Vibrate toy ff922f7fd345 at 16th strength, run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "command": "Function",
      "action": "Vibrate:16",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    // Vibrate 9 seconds at 2nd strength
    // Rotate toys 9 seconds at 3rd strength
    // Pump all toys 9 seconds at 4th strength
    // For all toys, it will run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "command": "Function",
      "action": "Vibrate:2,Rotate:3,Pump:4",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    // Stop all toys
    {
      "command": "Function",
      "action": "Stop",
      "timeSec": 0,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
  • Pattern Request

    If you want to change the way the toy responds very frequently you can use a pattern request. To avoid network pressure and obtain a stable response, use the commands below to send your predefined patterns at once.

    API URL: https://{domain}:{httpsPort}/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    rule"V:1;F:vrp;S:1000#"
    V:1; Protocol version, this is static;
    F:vrp; Features: v is vibrate, r is rotate, p is pump,this should match the strength below;
    S:1000; Intervals in Milliseconds, should be greater than 100.
    stringThe strength of r and p will automatically correspond to v.yes
    strengthThe pattern
    For example: 20;20;5;20;10
    stringNo more than 50 parameters. Use semicolon ; to separate every strength.yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will apply to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy as defined. The interval between changes is 1 second. Total running time is 9 seconds.
    {
      "command": "Pattern",
      "rule": "V:1;F:v;S:1000#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    // Vibrate the toys as defined. The interval between changes is 0.1 second. Total running time is 9 seconds.
    // If the toys include Nora or Max, they will automatically rotate or pump, you don't need to define it.
    {
      "command": "Pattern",
      "rule": "V:1;F:vrp;S:100#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
  • Preset Request

    API URL: https://{domain}:{httpsPort}/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    commandType of requestString/yes
    namePreset pattern namestringWe provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquakeyes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy with pulse pattern, the running time is 9 seconds.
    {
      "command": "Preset",
      "name": "pulse",
      "timeSec": 9,
      "toy": "ff922f7fd345",
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8

    Response Example:

    {
      "code": 200,
      "type": "ok"
    }

    1
    2
    3
    4

    Error Codes:

    CodeMessage
    500HTTP server not started or disabled
    400Invalid Command
    401Toy Not Found
    402Toy Not Connected
    403Toy Doesn't Support This Command
    404Invalid Parameter
    506Server Error. Restart Lovense Connect.
By server

If your application can’t establish a LAN connection to the user’s Lovense Remote app, you can use the Server API to connect the user’s toy.

⚠️ If you are using Lovense Remote for PC, you need to enter a code to establish connection. Use the code generated alongside the QR code in step 2 above.

pc-remote-code

  • Function Request

    API URL: https://api.lovense.com/api/lan/v2/command

    Request Protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Request Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringTo send commands to multiple users at the same time, add all the user IDs separated by commas. The toy parameter below will be ignored and the commands will go to all user toys by default.yes
    commandType of requestString/yes
    actionControl the function and strength of the toystringActions can be Vibrate, Rotate, Pump or Stop. Use Stop to stop the toy’s response.
    Range:
    Vibrate:0 ~ 20
    Rotate: 0~20
    Pump:0~3
    yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    loopRunningSecRunning timedoubleShould be greater than 1no
    loopPauseSecSuspend timedoubleShould be greater than 1no
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    stopPreviousStop all previous commands and execute current commandsintDefault: 1, If set to 0 , it will not stop the previous command.no
    apiVerThe version of the requestintAlways use 1yes

    Parameter stopPrevious are available in the following versions: Android Remote 5.2.2, iOS Remote 5.4.4, PC Remote 1.6.3 .

    Request Example:

    // Vibrate toy ff922f7fd345 at 16th strength, run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1132fsdfsd",
      "command": "Function",
      "action": "Vibrate:16",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    // Vibrate 9 seconds at 2nd strength
    // Rotate toys 9 seconds at 3rd strength
    // Pump all toys 9 seconds at 4th strength
    // For all toys, it will run 9 seconds then suspend 4 seconds. It will be looped. Total running time is 20 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1132fsdfsd",
      "command": "Function",
      "action": "Vibrate:2,Rotate:3,Pump:4",
      "timeSec": 20,
      "loopRunningSec": 9,
      "loopPauseSec": 4,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
  • Pattern Request

    If you want to change the way the toy responds very frequently you can use a pattern request. To avoid network pressure and obtain a stable response, use the commands below to send your predefined patterns at once.

    API URL: https://api.lovense.com/api/lan/v2/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Response Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringyes
    commandType of requestString/yes
    rule"V:1;F:vrp;S:1000#"
    V:1; Protocol version, this is static;
    F:vrp; Features: v is vibrate, r is rotate, p is pump,this should match the strength below;
    S:1000; Intervals in Milliseconds, should be greater than 100.
    stringThe strength of r and p will automatically correspond to v.yes
    strengthThe pattern
    For example: 20;20;5;20;10
    stringNo more than 50 parameters. Use semicolon ; to separate every strength.yes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will apply to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy as defined. The interval between changes is 1 second. Total running time is 9 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1ads22adsf",
      "command": "Pattern",
      "rule": "V:1;F:v;S:1000#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    // Vibrate the toys as defined. The interval between changes is 0.1 second. Total running time is 9 seconds.
    // If the toys include Nora or Max, they will automatically rotate or pump, you don't need to define it.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1ads22adsf",
      "command": "Pattern",
      "rule": "V:1;F:vrp;S:100#",
      "strength": "20;20;5;20;10",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
  • Preset Request

    API URL: https://api.lovense.com/api/lan/v2/command

    Request protocol: HTTPS Request

    Method: POST

    Request Content Type: application/json

    Request Format: JSON

    Parameters:

    NameDescriptionTypeNoteRequired
    tokenYour developer tokenstringyes
    uidYour user’s IDstringyes
    commandType of requestString/yes
    namePreset pattern namestringWe provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquakeyes
    timeSecTotal running timedouble0 = indefinite length
    Otherwise, running time should be greater than 1.
    yes
    toyToy IDstringIf you don’t include this, it will be applied to all toysno
    apiVerThe version of the requestintAlways use 1yes

    Request Example:

    // Vibrate the toy with pulse pattern, the running time is 9 seconds.
    {
      "token": "FE1TxWpTciAl4E2QfYEfPLvo2jf8V6WJWkLJtzLqv/nB2AMos9XuWzgQNrbXSi6n",
      "uid": "1adsf2323",
      "command": "Preset",
      "name": "pulse",
      "timeSec": 9,
      "apiVer": 1
    }

    1
    2
    3
    4
    5
    6
    7
    8
    9

Response Example:

{
  "result": true,
  "code": 200,
  "message": "Success"
}
1
2
3
4
5

Server Error Codes:

CodeMessage
200Success
400Invalid command
404Invalid Parameter
501Invalid token
502You do not have permission to use this API
503Invalid User ID
507Lovense APP is offline

Standard JS API

This solution allows you to control Lovense toys through your webpage.

Your users must use the Lovense Remote mobile app.

⚠️ iOS Remote v5.2.5+ or Android Remote v5.2.1+ is required.

⚠️ The user's devices must be in the same LAN.

Step 1: Set your Callback URL

Go to the developer dashboardopen in new window and set your Callback URL.

Set your Callback URL

Step 2: Import LAN.JS to your user's page

Add the LAN.JS to your user's page:

<script src="https://api.lovense.com/api/lan/v2/lan.js"></script>
1

Step 3: Handle the callback data from Lovense Remote

You can listen to the callback from Lovense Remote as below:

// the path should be the same as you set in the Lovense developer dashboard
@RequestMapping(value = "/api/lovense/callback")
public @ResponseBody
MessageResponse callback(@RequestBody Map body) {
  //TODO
  //send the callback data to the user's page and call `lovense.setConnectCallbackData` there
  return new MessageResponse(true, "success");
}
1
2
3
4
5
6
7
8

Call lovense.setConnectCallbackData to set when you receive the callback data from Lovense Remote.

lovense.setConnectCallbackData(callbackData)
1

⚠️ If the user uses Lovense Connect for PC, this step can be skipped because a QR code is not required.

Step 4: Command the toy(s)

Send commands/vibrations to Lovense toy(s) by calling lovense.sendCommand(parameters).

For the parameters list, see Command the toy(s).

Example:

lovense.sendCommand({
  command: "Function",
  action: "Vibrate:16",
  timeSec: 20,
  loopRunningSec: 9,
  loopPauseSec: 4,
  toy: "ff922f7fd345",
  apiVer: 1,
})
1
2
3
4
5
6
7
8
9

Other methods

  • getToys

    Get all toys, it will return all toys as an array

    lovense.getToys()

    1
  • getOnlineToys

    Get all online toys, it will only return the connected toys as an array

    lovense.getOnlineToys()

    1
  • isToyOnline

    Determine whether the toy is connected, it will return true as long as there is a toy connected.

    lovense.isToyOnline()

    1
  • openMobileRemote

    Open Lovense Mobile Remote.

    lovense.openMobileRemote()

    1

Native SDK

iOS SDK

The Lovense iOS SDK is a set of application interfaces based on iOS 8.0 and above. Use this SDK to develop applications for iOS mobile devices. By calling the Lovense SDK interface, you can easily control Lovense toys and build applications with rich functions and strong interactivity.

Download Demo

Step 1: Get your developer token

Go to the developer dashboardopen in new window and get your developer token.

Step 2: Download and extract the Lovense SDK

Download SDK

Step 3: Include the SDK in your project

Copy the following files to your project main directory.

Add the required framework Lovense.framework to your project.

Link Lovense IOS SDK

Configure environment: TARGETS -> General -> Deployment Info -> Deployment Target -> setting 8.0 or above.

Step 4: Connect Lovense toys and send commands

// import Lovense
#import <Lovense/Lovense.h>

// Pass your token into the Lovense framework
[[Lovense  shared] setDeveloperToken:@"Your token"];

// Add a scan success notification
[[NSNotificationCenter defaultCenter] addObserver:self selector:@selector(scanSuccessCallback:)
name:kToyScanSuccessNotification object:nil];      //Scanning toy success notification
-(void)scanSuccessCallback:(NSNotification *)noti
{
    NSDictionary * dict = [noti object];
    NSArray <LovenseToy*>* toys = [dict objectForKey:@"scanToyArray"];
}

// Add a connect success notification

[[NSNotificationCenter defaultCenter] addObserver:self selector:@selector(connectSuccessCallback:)
name:kToyConnectSuccessNotification object:nil];     //Connected toy successfully notification
-(void)connectSuccessCallback:(NSNotification *)noti
{
    NSDictionary * dict = [noti object];
    LovenseToy * toy = [dict objectForKey:@"toy"];
    NSLog(@"%@",toy);
}

// Search for the toys over Bluetooth
[[Lovense  shared] searchToys];

// Save the toys
[[Lovense  shared] saveToys:toys];

// Retrieve the saved toys
NSArray<LovenseToy*> * listToys = [[Lovense  shared] listToys];

// Connect the toy
[[Lovense shared] connectToy:toyId];

// Disconnect the toy
[[Lovense shared] disconnectToy:toyId];

// Send a command to the toy
[[LovenseBluetoothManager shared] sendCommandWithToyId:toyId
andCommandType:COMMAND_VIBRATE andParamDict:@{kSendCommandParamKey
_VibrateLevel:@(20)}];

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
Create YourProjectName-Bridging-Header.h

// Import Lovense
#import <Lovense/Lovense.h>

// Pass your token into Lovense framework
Lovense.shared().setDeveloperToken("token")

//Add a scan success notification
NotificationCenter.default.addObserver(self, selector: #selector(scanSuccessCallback),
name: NSNotification.Name(rawValue: kToyScanSuccessNotification), object: nil)
//Scanning toy success notification
@objc func scanSuccessCallback(nofi : Notification)
{
    let dict = nofi.object as? [String, LovenseToy]
    let scanToyArr = dict?["scanToyArray"]
}

//Add a connect success notification
NotificationCenter.default.addObserver(self, selector: #selector(connectSuccessCallback),
name: NSNotification.Name(rawValue: kToyConnectSuccessNotification), object: nil)
//Connected toy successfully notification
@objc func connectSuccessCallback(nofi : Notification)
{
    let dict = nofi.object as? [LovenseToy]
    let toy = dict?["toy"]
}

// Search the toys over Bluetooth
Lovense.shared().searchToys()

//Save the toys
Lovense.shared().save(toys)


// Retrieve the saved toys
Lovense.shared().listToys()

// Connect the toy
Lovense.shared().connectToy("toyId")

// Disconnect the toy
Lovense.shared().disconnectToy("toyId")

// Send a command to the toy
Lovense.shared().sendCommand(withToyId: "ToyId",
andCommandType: COMMAND_VIBRATE,
andParamDict: [kSendCommandParamKey_VibrateLevel:20])
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

Command list

CommandDescription
COMMAND_VIBRATEVibrate the toy. The parameter must be between 0 and 20.
COMMAND_ROTATERotate the toy. The parameter must be between 0 and 20.
COMMAND_ROTATE_CLOCKWISERotate clockwise. The parameter must be between 0 and 20.
COMMAND_ROTATE_ANTI_CLOCKWISERotate anti-clockwise. The parameter must be between 0 and 20.
COMMAND_ROTATE_CHANGEChange the rotation direction
COMMAND_AIR_INAirbag inflation for n seconds. The parameter must be between 1 and 3.
COMMAND_AIR_OUTAirbag deflation for n seconds. The parameter must be between 1 and 3.
COMMAND_AIR_AUTOCycle airbag inflation for n seconds and air deflation for n seconds. The parameter must be between 0 and 3 (0 means stop).
COMMAND_VIBRATE1Activate the first vibrator at level n. The parameter must be between 0 and 20.
COMMAND_VIBRATE2Activate the second vibrator at level n. The parameter must be between 0 and 20.
COMMAND_VIBRATE_FLASHVibrate the toy at level n and flash the light at the same time.
COMMAND_FLASHFlash the light 3 times
COMMAND_LIGHT_OFFTurn off the light (saved permanently).
COMMAND_LIGHT_ONTurn on the light (saved permanently).
COMMAND_GET_LIGHT_STATUSGet the light's status (1: on, 0: off)
COMMAND_ALIGHT_OFFTurn off Domi/Domi 2 light (saved permanently)
COMMAND_ALIGHT_ONTurn on the Domi/Domi 2 light (saved permanently)
COMMAND_GET_ALIGHT_STATUSGet the Domi/Domi 2 light status (1: on, 0: off)
COMMAND_GET_BATTERYGet battery status
COMMAND_GET_DEVICE_TYPEGet device/toy information
COMMAND_START_MOVEStart tracking the toy movement (0-4)
COMMAND_STOP_MOVEStop tracking the toy movement
COMMAND_PRESETVibrate with a preset pattern. Patterns range from 1 to 10. n=0 will stop vibrations.

Callback list

CallbackDescription
kToyScanSuccessNotificationFound toys
kToyConnectSuccessNotificationToy connected
kToyConnectFailNotificationFailed to connect a toy
kToyConnectBreakNotificationToy disconnection
kToySendCommandErrorNotificationUnknown command received
kToyCallbackNotificationBatteryBattery status
kToyCallbackNotificationDeviceTypeDevice information
kToyCallbackNotificationGetLightStatusLight indicator
kToyCallbackNotificationGetAidLightStatusDomi/Domi 2 light indicator
kToyCallbackNotificationListenMoveToy movement updates
kToyCommandCallbackNotificationAtSuccessSuccessful command
kToyCommandCallbackNotificationAtErrorCommand error

Android SDK

The Lovense Android SDK is a set of application interfaces based on Android 4.3 and above. Use this SDK to develop applications for Android mobile devices. By calling the Lovense SDK interface, you can easily control Lovense toys and build applications with rich functions and strong interactivity.

Download Demo

Step 1: Get the developer token

Go to the developer dashboardopen in new window and get your developer token.

Step 2: Download and extract the Lovense SDK

Download SDK

Step 3: Include SDK and Configure

  1. Copy the following file to your libs directory.

    Lovense Android SDK Path

  2. Add lovense.arr to your app build.gradle. Configure libs in the program build.gradle.

    app build.gradle:

    implementation files ('libs/lovense.aar')

    program build.gradle:

    Lovense Android SDK build config

  3. Configure permissions and register service in AndroidManifest.xml

    • Permission list

      <uses-permission android:name="android.permission.INTERNET" />
      <uses-permission android:name="android.permission.ACCESS_NETWORK_STATE"/>
      <uses-permission android:name="android.permission.BLUETOOTH" />
      <uses-permission android:name="android.permission.BLUETOOTH_ADMIN" />
      <uses-permission android:name="android.permission.ACCESS_COARSE_LOCATION" />
      <uses-permission android:name="android.permission.ACCESS_FINE_LOCATION" />

      1
      2
      3
      4
      5
      6
    • Register service

      <service android:name="com.xtremeprog.sdk.ble.BleService" android:enabled="true" />

      1

Step 4: Connect Lovense toys and send commands


// Pass your token into the Lovense framework
Lovense.getInstance(getApplication()).setDeveloperToken("Your token");

// Add a scan success notification
Lovense.getInstance(getApplication()).searchToys(new OnSearchToyListener() {
  @Override
  public void onSearchToy(LovenseToy lovenseToy) { } // Find toys

  @Override
  public void finishSearch() { }  // Scan finish

  @Override
  public void onError(LovenseError msg) { } // error

});

//Add a connection success notification
Lovense.getInstance(getApplication()).connectToy(toyId, new OnConnectListener() {
  @Override
  public void onConnect(String toyId,String status) { // Toy connection status
    switch (status) {
      case LovenseToy.STATE_CONNECTING:
        break;
      case LovenseToy.STATE_CONNECTED:
        break;
      case LovenseToy.STATE_FAILED:
        break;
      case LovenseToy.SERVICE_DISCOVERED:
        break;
    }
  }
  @Override
  public void onError(LovenseError lovenseError) {} // Connection error
 });

// Add sending command notification
Lovense.getInstance(getApplication()).addListener(toyId, new OnCallBack() {});

// Search for the toys over Bluetooth
Lovense.getInstance(getApplication()).addListener(toyId, new OnCallBack() {});

//Stop searching for toys
Lovense.getInstance(getApplication()).stopSearching();

// Save the toys
Lovense.getInstance(getApplication()).saveToys(lovenseToys, new OnErrorListener());

// Retrieve the saved toys
Lovense.getInstance(getApplication()).listToys(new OnErrorListener());

// Connect the toy
Lovense.getInstance(getApplication()).connectToy(toyId,new OnConnectListener());

// Disconnect the toy
Lovense.getInstance(getApplication()).disconnect(toyId);

// Send a command to the toy
Lovense.getInstance(getApplication()).sendCommand(toyId,LovenseToy.COMMAND _VIBRATE,vibrateLevel);
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59

Command list

CommandDescription
COMMAND_VIBRATEVibrate the toy. The parameter must be between 0 and 20.
COMMAND_ROTATERotate the toy. The parameter must be between 0 and 20.
COMMAND_ROTATE_CLOCKWISERotate clockwise. The parameter must be between 0 and 20.
COMMAND_ROTATE_ANTI_CLOCKWISERotate anti-clockwise. The parameter must be between 0 and 20.
COMMAND_ROTATE_CHANGEChange the rotation direction
COMMAND_AIR_INAirbag inflation for n seconds. The parameter must be between 1 and 3.
COMMAND_AIR_OUTAirbag deflation for n seconds. The parameter must be between 1 and 3.
COMMAND_AIR_AUTOCycle airbag inflation for n seconds and air deflation for n seconds. The parameter must be between 0 and 3 (0 means stop).
COMMAND_VIBRATE1Activate the first vibrator at level n. The parameter must be between 0 and 20.
COMMAND_VIBRATE2Activate the second vibrator at level n. The parameter must be between 0 and 20.
COMMAND_VIBRATE_FLASHVibrate the toy at level n and flash the light at the same time.
COMMAND_FLASHFlash the light 3 times
COMMAND_LIGHT_OFFTurn off the light (saved permanently).
COMMAND_LIGHT_ONTurn on the light (saved permanently).
COMMAND_GET_LIGHT_STATUSGet the light's status (1: on, 0: off)
COMMAND_ALIGHT_OFFTurn off Domi/Domi 2 light (saved permanently)
COMMAND_ALIGHT_ONTurn on the Domi/Domi 2 light (saved permanently)
COMMAND_GET_ALIGHT_STATUSGet the Domi/Domi 2 light status (1: on, 0: off)
COMMAND_GET_BATTERYGet battery status
COMMAND_GET_DEVICE_TYPEGet device/toy information
COMMAND_START_MOVEStart tracking the toy movement (0-4)
COMMAND_STOP_MOVEStop tracking the toy movement
COMMAND_PRESETVibrate with a preset pattern. Patterns range from 1 to 10. n=0 will stop vibrations.

Callback list

CallbackDescription
OnSearchToyListenerFound toy list
OnConnectListenerToy connected status
OnSendCommandErrorListenerSend Command error, extends OnCallBack
OnCallBackBatteryListenerBattery status, extends OnCallBack
OnCallBackDeviceTypListenerDevice information, extends OnCallBack
OnCallBackLightStatusListenerLight indicator, extends OnCallBack
OnCallBackAidLightStatusListenerDomi/Domi 2 light indicator, extends OnCallBack
OnCallBackMoveListenerToy movement updates, extends OnCallBack
OnCommandSuccessListenerCommand success, extends OnCallBack
OnCommandErrorListenerCommand Error, extends OnCallBack

Windows SDK

The Windows SDK is a library provided for Windows that allows you to directly access Lovense toys. You usually choose this option if you are making your own Windows application.

Download Demo

Step 1: Get your developer token

Go to the developer dashboardopen in new window and get your developer token.

Note: You need to fill in your developer token when using the SDK.

Step 2: Download SDK

Download SDK

Step 3: Configure the SDK in your application

For example, the method below is to configure SDK in Visual Studio 2019

  1. Set the path of the SDK header file

    configure head

  2. Set the path of SDK lib file

    configure libs

Step 4: Connect Lovense toys and send commands

#include <Lovense.h>
...
class CEventCallBack: public ILovenseSDKNotify
{
	public:
		/*Call when toy search start*/
		virtual	void LovenseDidSearchStart();

		/*Call when toy searching toy*/
		virtual  void LovenseSearchingToys(lovense_toy_info_t *info) = 0;

		/*Call when something went wrong*/
		virtual  void LovenseErrorOutPut(int errorCode,const char *errorMsg) = 0;


		/*Call when toy search end*/
		virtual  void LovenseDidSearchEnd();

		/*Call when send cmd start*/
		virtual	void LovenseDidSendCmdStart();

		/*Call when send cmd return*/
		virtual  void LovenseSendCmdResult(const char * szToyID, CLovenseToy::CmdType cmd,const char *result,CLovenseToy::Error errorCode);

		/*Call when send cmd end*/
		virtual	void LovenseDidSendCmdEnd();

		/*Call when toy connected, or disconnected*/
		virtual void LovenseToyConnectedStatus(const char *szToyID, bool isConnected) ;
};

...
	//TODO:This is a simple process
	CEventCallBack *callBack = new CEventCallBack();
	CLovenseToyManager *manager = GetLovenseToyManager();
	manager->SetDeveloperToken(...);
	manager->RegisterEventCallBack(callBack);
	manager->StartSearchToy();//Search for the toys via USB Dongle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38

Send a command

	CLovenseToyManager *manager = GetLovenseToyManager();
	//Send a vibration command
	manager->SendCommand(toyID,CLovenseToy::CmdType::COMMAND_VIBRATE,10);

1
2
3
4

For a list of supported commands, check LovenseDef.h

namespace CLovenseToy
{
	typedef enum {

		/**
		-Power off!
		- param Key = no parameter
		*/
		COMMAND_POWER_OFF = 100,

		/**
		- Vibrate the toy. The parameter must be between 0 and 20!
		- Supported toys = all
		*/
		COMMAND_VIBRATE = 101,

		/**
		- Rotate the toy. The parameter must be between 0 and 20!
		- Supported toys = Nora
		*/
		COMMAND_ROTATE = 102,
		.
		.
		.
	}
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

Setup

  1. Insert the Lovense USB Bluetooth Adapter into the PC.
  2. Turn on the toy. The light will begin flashing.
  3. Open your application and search for the toy to establish a connection.

Tips

  1. When searching for toys, do not send other commands to toys.
  2. If you need to get the toy's battery level frequently, start a thread loop.
  3. For best results, don't sent toy commands more than once per second.
  4. First time users, refer to our SDK Demo linked above.

View log output

To view log output, use the editbin command.

Note: If there is an "editbin not found" error when compiling, here is a solutionopen in new window.

view log

Last Updated: 6/28/2022, 2:28:46 PM
