Unreal Plugin For Remote

Introduction

This Unreal plugin allows Windows devices to connect Lovense toys and send control commands.

Note: Android and iOS Remote App requires "Game Mode" to be enabled, PC Remote App requires "Allow Control" to be enabled.

Compatibility

Unreal version: >= UE4.27

Import the plugin

1. Download the plugin package from here. The latest version of the current plugin is V1.23 click to view version records

   LovenseIntegration_4.27

   LovenseIntegration_5.0

   LovenseIntegration_5.1

   LovenseIntegration_5.2

   LovenseIntegration_5.3

   LovenseIntegration_5.4

2. Unzip the file to the /Plugins/ folder.

3. The file LovenseIntegration/Config/LovenseToySupportConfig.json is the configuration file for the toy support directive, and the version field represents the version of the information. The current latest version is 1.3. If it is older than this version, it is recommended to download and replace the file.

Dowload: LovenseToySupportConfig.json

Guide

1. Start Search

2. GetToys

3. Send Commands

3.1 Send Commands

• Description:

  Send function commands to the toys.



• Parameter:

  Name	Type	Default	Required	Description
  commands	TArray<UELovenseCommands>		yes	See UELovenseCommands
  toy	ULovenseToy		yes	the toy you want control
  time	float		yes	Total running time in second, 0 represents no limit
  loopRunningSec	float		yes	time running for each command loop in second
  loopPauseSec	float		yes	time gap for each command loop in second
  callback	FOnLovenseResponseDynamic		yes	the parameters is ULovenseToy* toy, int32 responseValue

3.2 Send Preset

• Description:

  Now we provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquake



• Parameter:

  Name	Type	Default	Required	Description
  toy	ULovenseToy*		yes	the toy you want to control
  name	FString		yes	The preset name to send, we provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquake
  timeSec	float		yes	The total runtime in second, "0" = indefinite time length. Otherwise, the value should be greater than or equal to 1.

3.3 Send Pattern

• Description:

  Send a series of functions to the toys.



• Parameter:

  Name	Type	Default	Required	Description
  toy	ULovenseToy*		yes	the toy you want control
  bVibrate	FString		yes	The preset name to send, we provide four preset patterns in the Lovense Remote app: pulse, wave, fireworks, earthquake
  bRotate	bool		yes	enable of rotate action
  bPump	bool		yes	enable of pump action
  bThrust	bool		yes	enable of thrusting action
  bSuck	bool		yes	enable of suck action
  bFinger	bool		yes	enable of fingering action
  interval	int		yes	The level interval in milliseconds ,Should be greater than 100
  timeSec	float		yes	The total runtime in second, "0" = indefinite time length. Otherwise, the value should be greater than or equal to 1.

3.4 Send stop command

• Description:

  Send a stop command to the toy.



• Parameter:

  Name	Type	Default	Required	Description
  toy	ULovenseToy*		yes	the toy you want control

4. Events API

4.1 Start Events API

• Description:

  Start Events API.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  port	int		yes	the Events API's port
  resultCodeCallback	FOnEventCode		yes	the result code of starting Events API, callback parameters is int resultCode,resultCode=-1: socket connection error,resultCode=0: socket closed,resultCode=200: socket connection successed.
  toysCallback	FOnGetLovenseEventToys		yes	If the Events API is successfully launched, it will respond with a list of toys that support the Events API in the Lovense Remote App, and the callback parameters is const TArray\<[UELovenseEventsToy]\> toys

4.2 Set connect event callback

• Description:

  Set callback for toy's connect status changed.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  connectCallback	FOnLovenseConnectStatusEvent		yes	callback for toy's connect status changed, and the callback parameters is FString id, bool isConnected

4.3 Set battery event callback

• Description:

  Set callback for toy's battery changed.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  batteryCallback	FOnLovenseConnectStatusEvent		yes	callback for toy's connect status changed,and the callback parameters is FString id, int32 battery

4.4 Set functions value event callback

• Description:

  Set callback for toy's functions value changed.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  functionsValueCallback	FOnFunctionsEvent		yes	callback for toy's function('See ELovenseEventType') value changed,and the callback parameters is (FString id, ELovenseEventType type,int32 value,int32 index)

4.5 Set every shake event callback

• Description:

  Set callback for each shake of the toys.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  everyShakeCallback	FOnEveryShakeEvent		yes	callback for each shake of the toys, and the callback parameters is FString id

4.6 Set button event callback

• Description:

  Set callback for the button gesture of the toys.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip
  buttonCallback	FOnButtonEvent		yes	callback for the button gesture of the toys,and the callback parameters is FString id, [ELovenseButtonEventType] type, int32 index

4.7 Stop Events API

• Description:

  Stop the Events API.



• Parameter:

  Name	Type	Default	Required	Description
  ip	FString		yes	the Events API's ip

5. Get Supported Commands

5.1 Toy is support this command

• Description:

  Determine whether specific types of toys support specific toys.



• Parameter:

  Name	Type	Default	Required	Description
  toyType	FString		yes	the toy type
  commandType	[ELovenseCommandType]		yes	the command type

• Return: bool

5.2 Get support commands by type

• Description:

  Get all supported command types based on toy type.



• Parameter:

  Name	Type	Default	Required	Description
  toyType	FString		yes	the toy type
  commandType	[ELovenseCommandType]		yes	the command type

• Return: TArray<[ELovenseCommandType]>

Class

ULovenseToy

Method

GetFullToyName

• Description:

  Get the toy's name

• Parameters: None

• Return: FString

GetAssociatedAdapterPlatformName

• Description:

  Get the Platform Name

• Parameters: None

• Return: FString

IsConnected

• Description:

  Whether this toy's connection to the Lovense App is active.

• Parameters:None

• Return: bool

GetBatteryStatus

• Description:

  Current battery status of the toy. Value is percentage charged, range is 0-100%.

• Parameters:None

• Return: int32

IsValidToy

• Description:

  Checks whether this is a valid UObject and has all required information for normal functionality.

• Parameters:None

• Return: bool

ELovenseCommandType

• Description:

  The enum of the toy function type.

• Enum:

  type	Range
  VIBRATE	0-20
  VIBRATE1	0-20
  VIBRATE2	0-20
  VIBRATE3	0-20
  ROTATE	0-20
  PUMP	0-3
  THRUST	0-20
  SUCTION	0-20
  FINGERING	0-20
  DEPTH	0-3

The DEPTH command is a setting command that requires the THRUSTRING command to take effect.

UELovenseCommands

• Description:

  Send the class containing the types and values of commands.

Property

name	type	Description
type	UELovenseCommands	the type of command
value	int	the value of command

Method

SetType

• Description:

  Set the type of commands.

SetValue

• Description:

  Set the value of commands.

UELovenseEventsToy

Property

name	type	Description
id	FString	the id of the toy
name	FString	the name of the toy
type	FString	the id of the toy
hVersion	FString	the hardware version of the toy
fVersion	int	the Firmware version of the toy
nickName	FString	the nick name of the toy
battery	int	the battery level of the toy
connected	bool	the connect status of the toy

ELovenseEventType

• Description:

  The enum of the toy function type.

• Enum:

  type
  VIBRATE
  ROTATE
  INFLATION
  THRUST
  SUCTION
  FINGERING
  SHAKE
  DEPTH

ELovenseButtonEventType

• Description:

  The enum of the button gesture type.

• Enum:

  type
  BUTTON_DOWN
  BUTTON_UP
  BUTTON_PRESSED

Version Records

[Version1.23] - 2024-05-15

• 1.Fix the thrust instruction.

• 2.Compatible with UE5.4.

[Version1.22] - 2024-01-16

• 1.Add capability with Mac OS X.

[Version1.21] - 2023-12-13

• 1.Add pre-built content.

[Version1.2] - 2023-11-15

• 1.Add Vibrate1,Vibrate2,Vibrate3,Depth commands

• 2.Add a function to obtain toy supported commands.and add an updatable configuration file

• 3.Update the configuration file to version1.3.

[Version1.1] - 2023-10-16

• 1.Add Events API.

[Version1.0] - 2023-09-21

• 1.Send Commands

• 2.Send Pattern Command

• 3.Send Preset Command

• 4.Send Stop Command
